High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM

  • High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM
Place of Origin Guangdong, China
Markenname JINPAT
Model Number LPCC-01B
Minimum Order Quantity 1
Preis $53

Treten Sie mit mir für freie Proben und Kupons in Verbindung.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skypen: sales10@aixton.com

Wenn Sie irgendein Interesse haben, leisten wir 24-stündige Online-Hilfe.

x
Produktdetails
Frequency Range DC to 6 GHz Max Rotating Speed 100rpm
Nut Material Brass Body Material Stainless Steel
Connector Type SMA-K Insertion Loss within 0.3dB
VSWR within 1.4 Working Speed 100RPM
Lifespan 1 million Type Electronic Accessories
Hervorheben

High Frequency Slip Ring DC-6GHz

,

Slip Ring for Radar Antennas

,

100RPM Fiber Optic Rotary Joint
Produkt-Beschreibung
High Frequency Rotary Joint with Small Size Radar Antennas Fiber Optic Slip Rings
Product Attributes
Attribute Value
Type Electronic Accessories
Frequency Range DC to 6 GHz
Rotating Speed, Max 100rpm
Nut Material Brass
Body Material Stainless Steel
Product Description
Bargain Price Only in Alibaba
JINPAT single-channel high frequency slip ring offers high frequency transmission solution between a fixed platform and a rotary platform, such as TV cameras, unmanned aerial vehicles and radar systems.
The slip ring allows signal transmission in the frequency range from DC up to 6GHz, and it can be integrated into the electrical slip ring to transmit power and high speed data. The high frequency slip ring is identified as ease of installation, ease of maintenance and optimal life.
Features
  • Connector type: SMA-K
  • Frequency range: DC-6GHz
  • Insertion Loss: within 0.3dB
  • VSWR: within 1.4
  • Working speed: 100RPM
  • Lifespan: 1 million rotations
Main Applications
  • Vehicle Turrets
  • Radar Antennas
  • Remotely Operated Vehicles
  • Video Surveillance Systems
  • Traffic Systems
Product Images
High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 0 High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 1
Our Advantages
  • With a large plant of over 12,000 square meters and more than 500 employees
  • National High and New Technology award winner with 69 patents
  • Long-term cooperation with global famous enterprises worldwide
  • Over 10,000 successful designs in civil, military, commercial and industrial applications
  • Founded in 1996 with more than 20 years of production and R&D experience
  • Free custom slip rings solutions for various equipment
  • Fast delivery service
High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 2
Company Information
High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 3 High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 4 High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 5 High Frequency Slip Ring DC-6GHz for Radar Antennas 100RPM 6
Frequently Asked Questions

1. What do we do?
We focus on developing, designing, manufacturing high quality sliprings, and offer various solutions for rotating systems.

2. What is a slip ring?
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.

3. What kinds of slip rings do we offer?

  • Electrical Slip rings (capsule slip ring, through-bore slip ring, miniature slip ring, etc)
  • Signal Slip rings (USB2.0/USB3.0 slip ring, fiber optic rotary joint, high frequency slip ring, etc)
  • Pneumatic/Hydraulic Rotary Unions
  • Custom Slip Rings
  • Large volume series

4. How do I choose a slip ring?
Proper selection requires details about your application's operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. Contact us for assistance in your selection.

5. Do you offer custom slip rings?
Yes, our engineers will create perfect solutions for your needs. Contact us to get started with custom slip ring solutions.
